Blackmagic Media Dock - product picture

Blackmagic Media Dock

Technical Specifications

Description

Blackmagic Media Dock is designed to transform post-production with speed and simplicity. It lets you connect and share up to three Blackmagic Media Modules from URSA Cine cameras across your entire team, so footage is ready to edit the moment you walk off set.With four independent 10G Ethernet ports, up to four edit stations can connect directly and work on the same media without duplication or delays. And with Ethernet over USB-C, Media Dock integrates seamlessly into a wide range of workflows.For reliability on critical productions, dual AC power inputs provide redundancy. Plus, an HDMI output lets you monitor media in real time on any TV or display — giving you confidence that every shot has been captured.Blackmagic Media Dock is more than storage. It’s a central hub that keeps your creative process moving, from camera to edit, faster than ever before.dundancy, and an HDMI output for real-time monitoring on any display.

Price

2,195.00 USD

Additional information

interface

3 x removable, hot-swappable Blackmagic Media Modules

10g-ethernet-ports

4 x 10G BASE-T

usb-c-port

1 x USB 3.0 (5Gb/s), supports Ethernet over USB

hdmi-monitor-outputs

1

computer-interface

USB-C or Ethernet for shared file access, configuration, and updates

file-sharing-protocol

SMB

cloud-synchronization

Amazon S3 sync, Blackmagic Cloud Storage

storage-type

Up to 3 Blackmagic Media Modules

external-storage-format

Blackmagic (formatted in camera)

hdmi-monitor-out-standards

1080p50, 1080p59.94, 1080p60

monitor-out-displays

Device name, storage capacity, Cloud sync, user activity, hardware status, storage map, network data rate

status-indicator

LED bezel indicator lights around module bays

external-control

USB-C or Ethernet for configuration and updates

software-included

Blackmagic Cloud Setup Utility, Proxy Generator Lite, firmware upgrade via Cloud Setup

operating-systems

MacOS Sonoma 14.3+, Windows 10 (64-bit), Windows 11

power-supply

Internal 100–240V AC, IEC C14 input

power-usage

95 W

physical-installation

2 rack units

environmental

Operating 0–40°C, Storage -20–60°C, Humidity 0–90%

whats-included

Blackmagic Media Dock, wallet with QR code
