Blackmagic PYXIS 12K EF is an advanced digital film camera designed with incredible versatility, giving you the freedom to build the perfect rig for any production.At its heart is a 12,288 x 8040 full-frame RGBW sensor with a built-in optical low-pass filter, delivering cinematic detail, true-to-life color, and an impressive 16 stops of dynamic range. With dual CFexpress media slots, recording at the highest quality is both fast and reliable.The fully customizable body features flexible mounting points and side plates, so you can adapt PYXIS to any shooting style. And with its fixed locking EF mount, it supports a wide range of Canon-compatible photo and cine lenses, offering filmmakers proven optical performance with secure, professional-grade stability.Blackmagic PYXIS 12K EF isn’t just a camera — it’s a powerful foundation for building your ultimate production system.
5,495.00 USD
| effective-sensor-size | 35.64 x 23.32 mm (Large Format) |
|---|---|
| pixel-pitch | 2.9 microns |
| lens-mount | Active, locking EF mount |
| lens-control | Iris and focus on supported lenses |
| dynamic-range | 16 stops |
| native-iso | 800 |
| shooting-resolutions | 12K (12288×8040, 12288×6912, 12288×6480, 12288×5112, 9648×8040); 9K (9408×6264, 8688×4896, 9312×4896, 9312×3864, 7680×6408); 8K (8192×5360, 8192×4608, 8192×4320, 8192×3408, 6432×5360); 4K (4096×2680, 4096×2304, 4096×2160, 4096×1704, 3216×2680) |
| frame-rates | 23.98–60 fps (project); max varies by resolution |
| high-frame-rates | Up to 112 fps (8K/4K 2.4:1); 90 fps (8K/4K 17:9); 84 fps (8K/4K 16:9); 72 fps (8K/4K open gate, 6:5); 80 fps (9K 2.4:1); 65 fps (9K 16:9/17:9); 50 fps (9K 3:2, 6:5); 60 fps (12K 2.4:1); 50 fps (12K 17:9); 45 fps (12K 16:9); 40 fps (12K open gate, 6:5) |
| focus | Autofocus with compatible lenses |
| iris-control | Wheel, touchscreen slider, auto iris button |
| screen | 4" LCD capacitive touchscreen, 1920×1080, 1500 nits |
| metadata-support | Auto lens data from electronic EF lenses; records settings, motion sensor, slate data, LUT embedding |
| controls | Touchscreen menus, push buttons, 3 assignable keys |
| timecode-clock | Highly accurate, <1 frame drift per 8 hours |
| connections | 1x 12G-SDI, 1x USB-C (viewfinder), 1x mini XLR, 1x 3.5mm stereo input, 1x 3.5mm headphone, Tri-Sync/Timecode, USB-C, 10G Ethernet |
| standards | HD: 1080p23.98–60, 1080i50–60; UHD: 2160p23.98–60; SDI SMPTE standards |
| audio | Stereo mic, mono speaker |
| media | 2x CFexpress Type B, 1x USB-C external drive |
| media-format | ExFAT, HFS+ |
| supported-codecs | Blackmagic RAW 3:1–18:1, Q0–Q5; H.264 Proxy 1080p |
| external-control | Zoom/Focus Demand, iPad, Bluetooth, USB PTP, REST API over Ethernet |
| network-management | NTP, Web Media Manager, FTP, SMB |
| storage | 2x CFexpress, 1x USB-C external; 12K up to 1,433 MB/s; 9K up to 857 MB/s; 8K up to 639 MB/s; 4K up to 336 MB/s |
| recording-formats | BRAW 3:1–18:1, Q0–Q5 with proxy H.264; multiple resolutions from 12K to 4K |
| software | Blackmagic OS, Resolve Studio, Camera Setup, RAW Player, QuickLook, RAW SDK, RAW Speed Test |
| operating-systems | MacOS Sonoma 14+, Sequoia 15+, Windows 10/11 |
| power-supply | 18V DC 90W external PSU |
| external-power-input | 2-pin Lemo locking connector |
| battery-type | BP-U series |
| power | 12–18V |
| optional-accessories | URSA Cine Handle, URSA Cine EVF, PYXIS Rosette Plate, PYXIS Monitor, PYXIS Monitor Kit, PYXIS Monitor EVF Kit |
| environmental | Operating 0–40°C, Storage -20–45°C, Humidity 0–90% |
| whats-included | PYXIS 12K EF, dust cap, standard plate, SSD plate, 90W PSU with adapters, welcome booklet, Resolve Studio key |
