DeckLink Duo 2 Mini is a low-profile PCIe capture and playback card with four independent 3G-SDI mini DIN connections. Supporting all SD and HD formats up to 1080p60, it gives you the flexibility of four capture or playback cards in one compact design. Completely customizable, it’s the perfect choice for media playout, multi-screen digital signage, real-time multi-channel capture, and more. DeckLink Duo 2 Mini — big performance in a low-profile design.
545.00 USD
| sdi-video-inputs | 4 x 3G-SDI mini DIN connections independently configurable as Input or Output and supports up to 12-bit SD and HD. |
|---|---|
| sdi-video-outputs | 4 x 3G-SDI mini DIN connections independently configurable as Input or Output and supports up to 12-bit SD and HD. |
| sdi-audio-inputs | 16 channels embedded in SD and HD. |
| sdi-audio-outputs | 16 channels embedded in SD and HD. |
| sync-input | Tri-Sync or Black Burst. |
| computer-interface | PCI Express 4 lane generation 2, compatible with 4, 8 and 16 lane PCI Express slots. |
| supported-codecs | AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, HEVC, XDCAM EX, XDCAM HD, XDCAM HD422, DNxHR & DNxHD, Apple ProRes 4444, Apple ProRes 422 HQ, Apple ProRes 422, Apple ProRes LT, Apple ProRes 422 Proxy, Uncompressed 8-bit 4:2:2, Uncompressed 10-bit 4:2:2, Uncompressed 10‑bit 4:4:4 |
| software-included | Media Express, Disk Speed Test, LiveKey, Blackmagic Desktop Video Utility and Blackmagic driver on Mac OS, Windows and Linux. |
| internal-software-upgrade | Firmware built into software driver. Loaded at system start or via updater software. |
| physical-installation | PCI Express 4 lane generation 2, compatible with 4 and 8 lane PCI Express slots on Mac OS, Windows and Linux. |
| software-applications | DaVinci Resolve, Fusion, Final Cut Pro X, Adobe Premiere Pro CC, Avid Media Composer, Adobe After Effects CC, Avid Pro Tools, Steinberg Cubase, Steinberg Nuendo, Adobe Photoshop CC, plus third-party apps. |
| video-standards-sd | 525i59.94 NTSC, 625i50 PAL |
| video-standards-hd | 720p50, 720p59.94, 720p60; 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59, 1080p59.94, 1080p60; 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30; 1080i50, 1080i59.94, 1080i60 |
| sdi-compliance | SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 425M, ITU-R BT.656 and ITU-R BT.601. |
| sdi-metadata-support | RP 188/SMPTE 12M-2 and closed captioning. |
| audio-sampling | Television standard sample rate of 48 kHz and 24 bit. |
| sdi-color-precision | 8, 10, 12-bit RGB 4:4:4 in all modes up to 1080p30; 8, 10-bit YUV 4:2:2 in all modes. 12-bit RGB 4:4:4 only supported in playback. |
| sdi-video-sampling | 4:2:2, 4:4:4 |
| color-space | REC 601, REC 709 |
| hdr-support | HDR static metadata packing, HLG and PQ transfer characteristics. |
| processing | Colorspace Conversion (hardware real time), HD Down Conversion (software, playback & capture), HD Up Conversion (software, input), Cross Conversion (software, playback). |
| real-time-effects | DaVinci Resolve, Final Cut Pro X internal effects, Adobe Premiere Pro CC Mercury Playback Engine effects, Avid Media Composer internal effects. |
| operating-systems | Mac 14.0 Sonoma, Mac 15.0 Sequoia or later; Windows 10 64-bit, Windows 11; Linux |
| power-consumption | 10 W |
| environmental-specifications | Operating Temp: 5° to 40°C, Storage Temp: -20° to 45°C, Humidity: 0% to 90% non-condensing. |
| whats-included | DeckLink Duo 2 Mini |
